Features:

• Electric power unit has convenient single phase, 110 volt operation for greater portability.
• Sturdy, welded channel iron frame for durability.
• Lever control ram advance for easy operation.
• Quiet, low pressure hydraulic components for greater efficiency and smooth pressing.
• Double acting cylinder allows for convenient positioning of ram.
• One hand ram positioning with 4-way valve hydraulic control.

Standard Equipment:

• Frame
• Two combination table plate/V-blocks
• Motor - 1 hp, 110 volt
• Pressure gauge
• Safety relief valve
• Lifting chain (on 25 ton model)

Specifications:

• Model | Force 25DA
• Capacity | 25 tons
• Horsepower | 1
• RPM | 1725
• Ram speed (per min.) | 10"
• Width between uprights | 28"
• Width between table channels | 7"
• Minimum ram to table | 8"
• Maximum ram to table | 44"
• Ram travel | 10"
• Base | 30" x 38"
• Height | 88"
• Weight | 570 lbs
