Features:

• Electric operation provides smooth, consistent pressing action.
• Variable ram speed allows fingertip control of ram movement for precise pressure control.
• H-frame mounted control allows convenient control of press when workhead is out of operator's reach.
• Adjustable table permits easy vertical movement by means of self-locking hoist.
• Double-acting cylinder permits pulling as well as pressing ram action.
• Safety valve protects against overloads.
• T-ring seals prevent pressure loss.
• Optional bolt flange for tooling attachment may be substituted for flat ram nose.

Shop Press Options:

• Table plates
• V-blocks

Specifications:

• Model | 42-502
• Operation | Elec-Draulic II
• Capacity Press (tons) /Table | 75/3800
• Ram Speed (in. per min.) Advance/Press/Return | -/5/15
• Horsepower | 2
• Width between uprights | 44"
• Width between table channels | 8-1/4"
• Min. Ram to Table | 13"
• Max. Ram to Table | 43-3/8"
• Ram Travel | 10"
• Table Travel | 22"
• Floor to Table Top | 30"
• Base | 47" x 52"
• Height | 116"
• Weight  | 2950 lbs
