• Three high-speed steel quick change knives provide rapid cutting, a superior finish and eliminates the need for a knife setting gauge
• Extra-long heavy-duty cast iron infeed and outfeed tables with precision machined finish
• Built-in rabbeting ledge adds versatility
• Two-way tilting fence with positive stops at 45° and 90° to handle bevel operations
• EXCLUSIVE front-mounted table adjustment handwheels make quick, easy and accurate corrections
• Industrial push-button controls are conveniently placed for easy access
• Built-in dust chute with 4" port connects to your collection system for efficient dust/chip disposal
• Center fence controls are conveniently mounted to allow quick adjustments
• Powerful 1HP motor easily handles the toughest jointing tasks
• Heavy-duty, one-piece steel closed stand includes mounting tabs for increased stability

Specifications:

• Part Number | 708457DXK
• Cutting Capacity | 6-1/16"w x 1/2"d
• Cutterhead Speed | 6000 RPM
• Number of Knives (Helical/Standard) | 3
• Standard Knife Size | 6-1/6"l x 3/4"w x 5/64"t
• Rabbeting Capacity | ½"
• Rabbeting Ledge | 3-1/8" x 8-3/4"
• Table Height | 31¼"
• Table Size | 56"l x 7-3/8"w
• Fence Size | 32-3/4"l x 3-7/8"h
• Fence Tilts | 45 ° left, 45 ° right
• Fence Positive Stops | 45 ° and 90 ° left, 90 ° right
• Dust Port Outside Diameter | 4"
• Dust Collection Minimum CFM Required | 350 cu.ft/min
• Motor Power | 1 HP
• Motor Phase | 1 Ph
• Motor Voltage | 115 / 230 V
• Prewired Voltage | 115 V
• Motor Current | 13 / 6.5 A
• Family Description | 6" LONG BED JOINTER
• Model Number | JJ-6CSDX
• Overall Dimensions | 56"l x 22"w x 37-1/2"h

• Net Weight | 237 lbs

PLEASE NOTE, IMPORTANT INFORMATION:

• This item ships by truck. Please notify Mile-X Equipment if residential or liftgate is required. Please note that for residential deliveries someone must be there to accept delivery. When ordering the checkout cart will incorrectly state that this ships by UPS.
