Laguna 37x2 Classic Double Drum Sander

Sand two grits in a single pass with a 37×2 Double Drum Sander. Featuring Intellisand Technology and a 5 HP 220 Volt 1 phase motor, you can significantly reduce the amount of time you spend sanding. The 37×2 Double Drum Sander features Intellisand Technology that auto-regulates the conveyor based on load, preventing burning, gouging, and damaging stock. The machine comes standard on an open-column base, and features a 5 HP motor. Available in Single phase only.

Features:

• Intellisand Technology: Automatically adjusts conveyor speed based on load
• Prevents gouging, damaging or burning stock
• Provides consistent finish even with varying grain pattern and density
• Greatly increases abrasive planing and dimensioning speed

Specifications:

• Maximum Sanding Width | 37″
• Minimum Sanding Length | 3-½″
• Maxiumum Sanding Thickness | 12″
• Minimum Sanding Thickness | 1/32″
• Dimensions | 43″H x 58″W x 31″D
• Drum (Extruded Aluminum) | 5″ x 37″
• Drum Speed | 1740 RPM
• Dust Hood (Steel Hood, Hinged At Back) | (3) – 4″ Vacuum ports, 1200 CFM minimum recommended
• Ball Bearings (1″) | 4, sealed and permanently lubricated
• Conveyor Motor | 254 in./lbs. torque, direct drive D.C. motor, ranged variable, 0-15 FPM
• Drive Motor (TEFC) | 5 HP
• Power Requirements | 208-230V, 60Hz, 1 Phase 30 Amp Service
• Shipping Dimensions | 62″L x 52″W x 45″H
• Shipping Weight |
• Casters Included | Yes
• Cord & Plug Included | No
