OTC 5668 Universal Cylinder Liner Puller

Designed to be used with an impact wrench for quick cylinder liner removal. The spring loaded puller arms automatically adjust to fit the liner for a fast set-up time. The low profile of this tool allows work in areas where space is limited. The tool accommodates bore diameters from 3-7/8" to 6-1/4", sleeve depths to 15", and liner wall thickness of 0.273" min. Drive screw hex size; 1-1/8". Works on select Mack, Volvo, Detroit Diesel, International, Cummins, Navistar and other Caterpillar engines. Similar to Porta-Tool OE tool number PT-6400-C.

Vehicle Applications:

• Mack
• Volvo
• Detroit
• International
• Cummins (except L10 and C series),
• Cat Engines 3176, 3196, 3300 Series, 3400 Series, 3500 Series, C10, C12, C15, C16
• Maxxforce DT, DT360, DTA360, DTA466, DT466, DT530 (PLN), DT466E, DT530E, DT570, HT570

Features:

• Similar to Porta-Tool OE tool number | PT-6400-C
• Cylinder bore diameter | 3-7/8" to 6-1/4"
• Liner wall thickness | 0.273" min
• Sleeve depth | Up to 15"
• Quickly removes heavy-duty cylinder liners
• Made in USA from global materials.

Specifications:

• Dimensions | 4.6" × 19.1" × 15.9"
• Product Weight | 28.1 lb
• Shipping Weight | 29 lb
